EVK-STD-CARRIER-S20

DC +12V ~ +24V Power input with 2.5mm DC Jack

Accept 1.8V VDDIO SMARC 2.0 compliant module

LVDS LCD backlight control signals

RTC backup battery holder (CR2302)

Buzzer

single/dual-channel LVDS, HDMI and DisplayPort Supported

2 x 10/100/1000Mbps RJ-45 connectors

2 x USB 2.0 host type A connectors, 2 x USB 3.0 host type A connectors, 1 x mini USB client connector

2 x CAN BUS headers, 4 x RS232 (Two with DB9 can be configured as RS422/485, two with 2.0mm headers), 1 x 2x7-pin 2.0mm GPIO header, 3 x I2C 2.0mm headers (for capacitive touch), 2 x SPI 2.0mm headers and 2 x ESPI 2.0mm headers

3.5mm Audio Jack for Microphone Input and Headphone Output

1 x SDHC connector

1 x SATA Connector

1 x SATA Power Connector

1 x 2-LANE and 1 x 4-LANE CAMERA interfaces for camera modules

1 x PCIex4 and 2 x mini-PCIe Connectors

A single 4KB EEPROM is provided on I2C0 that holds the board information. This information includes board name, serial number, and revision information.

1 x external watchdog reset

jumpers and switches for LCD 3.3V or 5V voltage, boot selection, RS232 or RS485 selection, GPIO and USB path selection

Form Factor: mini-ITX (170mm x 170mm, L x W)

DC +12V ~ +24V Power input with 2.5mm DC Jack

Accept 1.8V VDDIO SMARC 2.0 compliant module

LVDS LCD backlight control signals

RTC backup battery holder (CR2302)

Buzzer

single/dual-channel LVDS, HDMI and DisplayPort Supported

2 x 10/100/1000Mbps RJ-45 connectors

2 x USB 2.0 host type A connectors, 2 x USB 3.0 host type A connectors, 1 x mini USB client connector

2 x CAN BUS headers, 4 x RS232 (Two with DB9 can be configured as RS422/485, two with 2.0mm headers), 1 x 2x7-pin 2.0mm GPIO header, 3 x I2C 2.0mm headers (for capacitive touch), 2 x SPI 2.0mm headers and 2 x ESPI 2.0mm headers

3.5mm Audio Jack for Microphone Input and Headphone Output

1 x SDHC connector

1 x SATA Connector

1 x SATA Power Connector

1 x 2-LANE and 1 x 4-LANE CAMERA interfaces for camera modules

1 x PCIex4 and 2 x mini-PCIe Connectors

A single 4KB EEPROM is provided on I2C0 that holds the board information. This information includes board name, serial number, and revision information.

1 x external watchdog reset

jumpers and switches for LCD 3.3V or 5V voltage, boot selection, RS232 or RS485 selection, GPIO and USB path selection

Form Factor: mini-ITX (170mm x 170mm, L x W)

DC +12V ~ +24V Power input with 2.5mm DC Jack

Accept 1.8V VDDIO SMARC 2.0 compliant module

LVDS LCD backlight control signals

RTC backup battery holder (CR2302)

Buzzer

single/dual-channel LVDS, HDMI and DisplayPort Supported

2 x 10/100/1000Mbps RJ-45 connectors

2 x USB 2.0 host type A connectors, 2 x USB 3.0 host type A connectors, 1 x mini USB client connector

2 x CAN BUS headers, 4 x RS232 (Two with DB9 can be configured as RS422/485, two with 2.0mm headers), 1 x 2x7-pin 2.0mm GPIO header, 3 x I2C 2.0mm headers (for capacitive touch), 2 x SPI 2.0mm headers and 2 x ESPI 2.0mm headers

3.5mm Audio Jack for Microphone Input and Headphone Output

1 x SDHC connector

1 x SATA Connector

1 x SATA Power Connector

1 x 2-LANE and 1 x 4-LANE CAMERA interfaces for camera modules

1 x PCIex4 and 2 x mini-PCIe Connectors

A single 4KB EEPROM is provided on I2C0 that holds the board information. This information includes board name, serial number, and revision information.

1 x external watchdog reset

jumpers and switches for LCD 3.3V or 5V voltage, boot selection, RS232 or RS485 selection, GPIO and USB path selection

Form Factor: mini-ITX (170mm x 170mm, L x W)

SMARC 2.0 Carrier Board Design Guide

User's Manual

Carrier Board Reference Schematics (pdf and OrCAD format)

Carrier Board Schematics Checklist

SMARC PinMux file

P/N: EVK-STD-CARRIER-S20
