OSM-iMX93-SF

NXP i.MX9352 2 x 1.7GHz Cortex-A55 Core

Real-time 250Mhz ARM Cortex-M33

ARM Ethos-U65 microNPU (ML) 0.5 TOPs

PxP 2D GPU

16-bit 1GB/2GB LPDDR4x up to 3200MT/s

16GB eMMC (5.x) onboard

M24C32 EEPROM onboard

4-LANE MIPI DSI (up to 1920 × 1200@ 60 Hz or 1920x1080p60)

1 x 2-lane MIPI-CSI

2 x 4-bit SDIO card interface with support lines

Typically used for connection to I2S audio CODECs

Five asynchronous serial ports

Two ports supporting four-wire handshaking (RXD, TXD, RTS#, CTS#).

Three ports supporting data-only signals (RXD, TXD).

Logic level signals from Module based FlexCAN bus protocol controllers

RXD and TXD only

One USB OTG 2.0 Ports with PHY

One USB 2.0 Host with PHY

USB support signals (VBUS enable, Over-current detect, USB ID signals)

Two GbE MDI interfaces

One port supports QoS with TSN

PHY and magnetics are not on Module

LED support signals

3 x PWMs

2 x ADCs

Module eMMC Flash (Default)

Carrier SD Card (Recovery)

5V +/- 5% power input voltage

1.8V VDDIO
